| Brand Name: | VIKSTARS |
| Model Number: | VS-LH-F |
| MOQ: | 20pcs |
| Packaging Details: | VS-LH-F20, Lamp Size: 66.3*24*9cm, QTY/CTN: 5pcs/ctn, CTN SIZE: 67.5*50*26.5cm |
| Payment Terms: | T/T, Western Union |
|
LAMP NAME
|
INTEGRATED SOLAR STREET LIGHT
|
|
|---|---|---|
| MODEL NO. |
VS-LH-F20
|
VS-LH-F30 |
| POWER |
200W
|
300W |
| BATTERY | 3.2V 20AH | 3.2V 35AH |
| SOLAR PANEL | Mono 5V 25W | Mono 5V 35W |
| LUMEN |
1300lm
|
2340lm |
| LED QUANTITY | 5054*77pcs | 5054*119pcs |
| BEAM ANGLE | 70*140° | |
| CCT |
Default: Cold White
|
|
| C.R.I. | >70Ra | |
| CHARGE TIME |
4-6 hours
|
|
| LASTING TIME | 3-5 rainy days | |
| INSTALL HEIGHT | 3-4m | 5-6m |
| LIGHTING AREA | 20-30㎡ | 30-40㎡ |
| WORKING MODE |
Light Sensor + Motion Sensor / Light Sensor + Time Control
( Supports two modes at the same time, switch via remote control )
|
|
| INSTALL WAY | Horizontal Install / Vertical Install | |
| WATERPROOF | IP66 | |
| MATERIAL | Galvanized Steel Heat Sink + PC Lens / Sand Grey | |
| LAMP SIZE | 663*240*90mm | 835*240*90mm |
| SOLAR PANEL SIZE | 566*236mm | 736*236mm |
| PACKING |
Individual inner color box packaging
(not include lamp pole, need to buy additionally )
|
|
| WARRANTY | 5 years | |
WORKING MODE
|
AT DAY - AUTO CHARGE
Indicator light flashes, auto charges,
fully charged in 4-6 hours,
can also be charged in the cloudy / rainy days
|
AT NIGHT - AUTO LIGHT UP
When built-in Light sensor detects darkness,
the lamp auto lights up,
can last 3-5 rainy days after fully charged
|
|
MOTION SENSOR
People come, 100% brightness
People leave after 15s, 30% brightness
|
TIME CONTROL
Constant-on mode dimming schedule:
100% brightness (30min) → 70% (1.5h) →
50% (4h) → 40% (1h) → 25% (1h) → 20% (4h),
daily cycle.
|
|
Straight Arm Install Horizontal Installation |
Adjustable Arm Install Horizontal / Vertical Installation |
INSTALL HEIGHT
REAL PHOTOs
|
Power
|
Color box size | Carton Size |
Qty/ctn
|
G.W. | Packing |
|---|---|---|---|---|---|
| 200W | 250*95*640mm | 675*500*265mm |
5pcs/ctn
|
|
Export Neutral Carton
/ VIKSTARS Brand / Customizing Packing |
| 300W | 250*95*810mm | 845*500*265mm |
|
|
| Brand Name: | VIKSTARS |
| Model Number: | VS-LH-F |
| MOQ: | 20pcs |
| Packaging Details: | VS-LH-F20, Lamp Size: 66.3*24*9cm, QTY/CTN: 5pcs/ctn, CTN SIZE: 67.5*50*26.5cm |
| Payment Terms: | T/T, Western Union |
|
LAMP NAME
|
INTEGRATED SOLAR STREET LIGHT
|
|
|---|---|---|
| MODEL NO. |
VS-LH-F20
|
VS-LH-F30 |
| POWER |
200W
|
300W |
| BATTERY | 3.2V 20AH | 3.2V 35AH |
| SOLAR PANEL | Mono 5V 25W | Mono 5V 35W |
| LUMEN |
1300lm
|
2340lm |
| LED QUANTITY | 5054*77pcs | 5054*119pcs |
| BEAM ANGLE | 70*140° | |
| CCT |
Default: Cold White
|
|
| C.R.I. | >70Ra | |
| CHARGE TIME |
4-6 hours
|
|
| LASTING TIME | 3-5 rainy days | |
| INSTALL HEIGHT | 3-4m | 5-6m |
| LIGHTING AREA | 20-30㎡ | 30-40㎡ |
| WORKING MODE |
Light Sensor + Motion Sensor / Light Sensor + Time Control
( Supports two modes at the same time, switch via remote control )
|
|
| INSTALL WAY | Horizontal Install / Vertical Install | |
| WATERPROOF | IP66 | |
| MATERIAL | Galvanized Steel Heat Sink + PC Lens / Sand Grey | |
| LAMP SIZE | 663*240*90mm | 835*240*90mm |
| SOLAR PANEL SIZE | 566*236mm | 736*236mm |
| PACKING |
Individual inner color box packaging
(not include lamp pole, need to buy additionally )
|
|
| WARRANTY | 5 years | |
WORKING MODE
|
AT DAY - AUTO CHARGE
Indicator light flashes, auto charges,
fully charged in 4-6 hours,
can also be charged in the cloudy / rainy days
|
AT NIGHT - AUTO LIGHT UP
When built-in Light sensor detects darkness,
the lamp auto lights up,
can last 3-5 rainy days after fully charged
|
|
MOTION SENSOR
People come, 100% brightness
People leave after 15s, 30% brightness
|
TIME CONTROL
Constant-on mode dimming schedule:
100% brightness (30min) → 70% (1.5h) →
50% (4h) → 40% (1h) → 25% (1h) → 20% (4h),
daily cycle.
|
|
Straight Arm Install Horizontal Installation |
Adjustable Arm Install Horizontal / Vertical Installation |
INSTALL HEIGHT
REAL PHOTOs
|
Power
|
Color box size | Carton Size |
Qty/ctn
|
G.W. | Packing |
|---|---|---|---|---|---|
| 200W | 250*95*640mm | 675*500*265mm |
5pcs/ctn
|
|
Export Neutral Carton
/ VIKSTARS Brand / Customizing Packing |
| 300W | 250*95*810mm | 845*500*265mm |
