| Brand Name: | VIKSTARS |
| Model Number: | VS-STL-C |
| MOQ: | 20pcs |
| Price: | Negotiable |
| Packaging Details: | ITEM:VS-STL-C20 Lamp size: 290*665*85mm, Lamp Carton: 58*33.5*15cm, 1pc/ctn |
| Payment Terms: | T/T |
Good Price 50W 100W 150W 200W LED Street Lights With Photocell 7pins Socket For Project Wholesale
DELIVERY
| LAMP NAME | LED STREET LIGHT | |||
| MODEL NO. | VS-STL-C05 | VS-STL-C10 | VS-STL-C15 | VS-STL-C20 |
| POWER | 50W | 100W | 150W | 200W |
| INSTALL HEIGHT | 3-4m | 5-6m | 6-8m | 8-10m |
| LED QTY | 96pcs | 144pcs | 240pcs | 320pcs |
| BEAM ANGLE | 70*140° | |||
| VOLTAGE | 85-265Vac | |||
| PF | >0.95 | |||
| CCT | Default: Cold White (Warm White / Neutral White for option) | |||
| C.R.I. | ＞70Ra | |||
| INSTALL WAYS |
Horizontal Install / Vertical Install / Wall Install / Hug Hoop Install (Accessories not include hug hoop, need to buy additionally) |
|||
| WATERPROOF | IP65 | |||
| MATERIAL | Die-casting Aluminum Heat Sink + PC lens + Glass Cover / Sand Grey | |||
| LAMP SIZE | 220*515*85mm | 220*565*85mm | 240*635*85mm | 290*665*85mm |
| HOLDER DIAMETER | Ø60mm | |||
| PACKING | Export Neutral Carton / VIKSTARS Brand / Customizing Packing | |||
|
SOLUTION
|
Project Solution
|
Top-level Solution |
Top-level Solution-Photocell
|
| LEDs TYPE | 3030 | Big Chip 3030 | |
| LUMEN EFFICIENCY |
130lm/w
|
160lm/w | |
| DRIVER |
VIKSTARS
Self-Developed Driver
|
Global Certified
MEANWELL Driver
|
|
| WARRANTY |
3 Years
|
5 Years
|
|
| Horizontal Install | Vertical Install | Hug Hoop Install | Wall Install |
| Power | Carton Size | Qty/ctn | G.W. | Packing |
| 50W | 430*250*150mm | 1pc/ctn | 2.55kg |
Export Neutral Carton Packing / VIKSTARS Brand Packing / Customizing Packing |
| 100W | 480*270*150mm | 1pc/ctn | 3.2kg | |
| 150W | 550*290*150mm | 1pc/ctn | 4.00kg | |
| 200W | 580*335*150mm | 1pc/ctn | 4.80kg |
|
|
