Product Details:
|
| Warranty: | 2-5 Years | Application: | Sport Field |
|---|---|---|---|
| CRI (Ra>): | 70 | Lamp Luminous Efficiency(lm/w): | 100-150lm/w |
| Working Time (hours): | 50000 | Product Name: | Ufo High Bay |
| High Light: | Gyms ufo led high bay light,SMD 3030 ufo led high bay light,Isolated Driver high bay ufo lights |
||
3 Years Warranty Ufo High Bay Constant Isolated Driver Gyms Lighting
Advantages:
1. Our this ufo high bay , according to different parameter configuration, we offer 2 / 3 / 5 years warranty , During warranty period, we can offer free compensation accordingly
2. Strictly quality control, and 100% inspection before shipment, usually the lifespan of our this ufo high bay can reach 35000 - 50000 hrs .
3. Our most light are with CE ( EMC , LVD ) and RoHs certificates, some also are CB, IEC, listed , if projects require other certificates, we can also support clients to do the required testing, to get the certificates from our side .
Specification:
| Product Name | ufo high bay | ||||
| Model No |
VS-UFO-C05
|
VS-UFO-C10
|
VS-UFO-C15
|
VS-UFO-C20
|
VS-UFO-C24
|
| Power |
50W
|
100W
|
150W
|
200W
|
240W
|
| LED Qty |
98 LEDs
|
140 LEDs
|
210 LEDs
|
280 LEDs
|
280 LEDs
|
| Size |
Ф240*150mm
|
Ф288*150mm
|
Ф340*165mm
|
Ф390*195mm
|
Ф390*225mm
|
| Package |
27*27*15cm
|
32*32*15cm
|
37*37*17cm
|
46*46*22cm
|
46*46*25cm
|
| NW |
1.5kg
|
2.1kg
|
3.0kg
|
4.6kg
|
6.2kg
|
| Voltage | 85 - 265V / 277V | ||||
| LED Type | SMD 3030 LEDs | ||||
| C.R.I | >70Ra | ||||
| Lumen Efficiency | 100 - 150 lm / w | ||||
| IP Rating | IP65 | ||||
| Color Temp | 6000K | ||||
| Working Temp | -20℃ - 50℃ | ||||
| Beam Angle | 60 / 90 / 120 Degree | ||||
| Installation | Hook / Bracket | ||||
| Lifespan | >50000 hrs | ||||
| Warranty | 2 - 5years | ||||
| Application | Garage, Factory, indoor sports field,badminton court Lighting | ||||
| Materials | Aluminum heat sink, PC lens, Stainless screws, waterproof rubber ring, waterproof connector | ||||
Miss.Lillian
VIKSTARS CO., LIMITED
Tel/wechat: +8615302738576
E-mail: vs602@vikstars.com
Http://www.vikstars.com
Q1. Can I have a sample order for ufo high bay ?
A: Yes, VS welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the VS lead time ?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than.
Q3. Does VS have any MOQ limit for ufo high bay order ?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive ?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
