Product Details:
|
| Application: | Indoor Sports Field/badminton Court | Keyword: | Led High Bay Lights |
|---|---|---|---|
| Light Source: | LED | LED Driver: | Constant Isolated Driver |
| Control Mode: | Switch Control | Lamp Luminous Flux(lm): | 5000~36000LM, 5000~31200LM |
| High Light: | 120Degree LED High Bay Lights,36000LM LED High Bay Lights |
||
Advantages:
1. If you want to do some led high bay lightst changes on this led high bay lightst, like changing its color, adding auxiliary accessories, laser your logo on it, Something like this, we can support you for free of charge.
2. We designed 2 lens for option, usually we use granular lens, looks firm and textured, if higher lumen needed, we can use ring lens, with this lens can reach 150 - 160 lm/w.
3. Between the driver box & lamp body, we adopted a separating design, so the air can go between easily, taking away the heat, also we deigned many holes around the lamp body, so the air flowing up and down can take the heat away well.
| Product Name | led high bay lights | ||||
|
Model No
|
VS-UFO-C05
|
VS-UFO-C10
|
VS-UFO-C15
|
VS-UFO-C20
|
VS-UFO-C24
|
|
Power
|
50W
|
100W
|
150W
|
200W
|
240W
|
|
LED Qty
|
98 LEDs
|
140 LEDs
|
210 LEDs
|
280 LEDs
|
280 LEDs
|
|
Size
|
Ф240*150mm
|
Ф288*150mm
|
Ф340*165mm
|
Ф390*195mm
|
Ф390*225mm
|
|
Package
|
27*27*15cm
|
32*32*15cm
|
37*37*17cm
|
46*46*22cm
|
46*46*25cm
|
|
NW
|
1.5kg
|
2.1kg
|
3.0kg
|
4.6kg
|
6.2kg
|
| Voltage | 85 - 265V / 277V | ||||
| LED Type | SMD 3030 LEDs | ||||
| C.R.I | >70Ra | ||||
| Lumen Efficiency | 100 - 150 lm / w | ||||
| IP Rating | IP65 | ||||
| Color Temp | 6000K | ||||
| Working Temp | -20℃ - 50℃ | ||||
| Beam Angle | 60 / 90 / 120 Degree | ||||
| Installation | Hook / Bracket | ||||
| Lifespan | >50000 hrs | ||||
| Warranty | 2 - 5years | ||||
| Application | Garage, Factory, indoor sports field,badminton court Lighting | ||||
| Materials | Aluminum heat sink, PC lens, Stainless screws, waterproof rubber ring, waterproof connector | ||||
Q1. Does VS offer guarantee for the led high bay lights ?
A: Yes, we offer 2-5 years warranty to our products.
Q2. Can I have a sample order for led high bay lights ?
A: Yes, VIKSTARS welcome sample order to test and check quality. Mixed samples are acceptable.
Q3. What about the VS lead time ?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than.
Q4. Is it OK to print my logo on lamp ?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
